The system is designed to fully replace exterior classical mirrors. The mirror automatically adjusts its brightness in different lighting conditions free of glare or reflections. The driver will have better visibility under all challenging weather scenarios.

Digital Rearview Camera Monitor System ( CMS ) UNECE R46 Standard

In compliance with the technical criteria of UNECE R46, the interior digital rear view mirror is meticulously designed to replace traditional exterior rear view mirrors. It eliminates glares and adjusts brightness of the mirror automatically. The intelligent system features a blind spot detection system ( BSD ) eradicating blind spots and ensuring your safety on the road. A 360 degree surround view camera system can be connected for a comprehensive view around your vehicle. Night vision cameras capture clear videos even at dark night. The system is compatible with a wide range of vehicles and is perfect for commercial vehicle operators, fleet managers, and professional drivers that prioritize safety, efficiency and cutting-edge technology in their vehicles.

Highlighted Features

  1. The smart interior rearview mirror is designed for a wide range of commercial vehicles like passenger buses, coaches, trucks, oil tanks, trailers, forklifts, etc. It is used to completely replace the traditional rearview mirrors.
  2. HD cameras with wider field of vision and superior visibility that eradicates the lateral blind spots and minimizes risks of collisions and accidents.
  3. The intelligent system eliminates glares and adjust automatically the brightness of the mirrors in all light and weather conditions.
  4. Automotive grade display mirrors show crystal clear videos even in harsh sun rays.
  5. Double curvature mirrors help reduce the blind area as much as possible.
  6. Drivers can read and watch the mirror videos even in polaroid sunglasses. The mirror adjusts its brightness automatically dependent on changes of its surrounding lights.
  7. Night vision cameras ensure optimal visibility during nighttime driving.
  8. BSD smart system alerts drivers of the vehicles and pedestrians that occur in their blind spots.
  9. 360 degree surround view camera system provides a better all-round vision surrounding your vehicle.
  10. The technical specifications of the digital rearview mirror meet the requirements of UNECE R46 Regulation and has passed the verification of GB15084-2022, the state standard of China which has the same technical specifications of UNECE R46 Regulation.

Upgrade to our advanced rear view camera monitor system ( SMS ) and experience the convenience, safety and peace of mind that comes with our cutting-edge technology.

Contact MacFaith today to learn further details. Our experienced team will be happy to answer your questions and provide a customized solution to meet your specific needs.

Technical Specifications

System Linux
Display monitor TFT-LCD 12.3 inch ( 8:3 ) IPS
Resolution 1920×3(RGB) x 720 Pixel
Brightness 1000cs/m2
Contrast   ratio 1000:1
Viewing angle U/D:   450/450   L/R: 450/450
SOC Hisilicon HI3521A
SOC processor CoretxA9 1GHzx2 + VianteGc2000
RAM 1600MHz_DDR3_2GBx2
ROM SPI_NandFlash_512MB
Video channel AHD1920x1080
Control   interface RS232/UART
Storage interface TF/Msata
Video resolution 1920 x 1080
Rated operational voltage 24V
Rated operational current 350mA
Power <10W
Operating temperature -30   ~ -800C
Storage   temperature -40   ~ -950C
Dimensions 330 x 150 x 29mm
NWT 1000g

Product Structure and Relevant Diagrams

Display Mode Settings
